Frameset
-
Frame
Moterra Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm two-bolt kickstand mount -
Fork
RockShox Lyrik Select+, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset -
Headset
Acros integrated sealed bearing, tapered -
Rear Shock
RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound
E-System
-
Drive Unit
Bosch Performance Line CX 250W -
Battery
Bosch PowerTube, 750Wh -
Charger
Bosch 4A -
Display
Bosch Kiox 300 w/ LED remote -
Certifications
UL2849
Drivetrain
-
Rear Derailleur
Shimano XTR -
Shifters
Shimano XT, 12-speed -
Chain
Shimano XT, 12-speed -
Crank
FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T -
Rear Cogs
Shimano XT, 10-51, 12-speed
Brakes
-
Brakes
Shimano XT 8120 4-piston hydraulic disc, 203/203mm RT76 rotors -
Brake Levers
Shimano XT hydraulic disc
Wheels
-
Rims
WTB KOM Trail i30 TCS, 32h, tubeless ready -
Spokes
DT Swiss Champion -
Tire Size
2.6 -
Wheel Size
29 -
Hubs
(F) Formula 15x110mm thru-axle / (R) DT Swiss, 12x148mm thru-axle -
Tires
(F) Maxxis Minion DHF, 29×2.6″, EXO, tubeless ready / (R) Maxxis Rekon, 29×2.6″ (27.5×2.6″ – size Small), EXO, tubeless ready -
Front Tire
Maxxis Minion DHF, 29×2.6″, EXO, tubeless ready -
Rear Tire
Maxxis Rekon, 29×2.6″ (27.5×2.6″ – size Small), EXO, tubeless ready
Components
-
Handlebar
HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm -
Stem
Cannondale 2, 6061 Alloy, 35mm, 0° -
Grips
Fabric FunGuy -
Saddle
Fabric Scoop Shallow Elite, cro-mo rails -
Seatpost
Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
Extra
-
Extra 1
Lezyne Super HB STVZO E1000 w/ remote high beam switch.
